| baling Chamber | 25” X 18” X 52” (H X W X L) (2 Cyl) |
| bale Size | 16” X 18” (H X W ) |
| electric Motor | 15 H.p 3 Phase 1440 Rpm 50 Hzs |
| body | fabricated 45 Mm |
| hard Liner Plates | provided ( C 45 ) |
| oil Drive | double Pump Syatems |
| working Liquid | hydro/enclo-68 (Not In Our Scope) |
| no Of Cylinder | 2 Nos |
| force On Lid | 40 Tons (140 Bore X 170 Od X90 Ram) |
| force On Main Cylinder | 80 Tons (200 Bore X 245 Od X 135 Ram) |
| door Lock Cylinder | by Mannual |
| bale Eject Cylinder | by Main Force Cylinder |
| working Pressure | 3000 Psi |
| bale Eject | by Cylinder |
| door Lock | mannual |
| starter | provided |
| idle Cycle Time | 50 -60 Seconds (Approx) |
| weight Of The Bale | ms / Ss 30 To 50 Kgs. |
| oil Tank Capacity | 400 Lts. |
| operation Of The Machine | manual 2 Through Levers |
| usage/application | Aluminium, Copper, Light Scrap |
